Voltage:DC24V
Power:24watt
PCB Width:15mm
Colors:white/warm white/red/green/blue/yellow/pink/ice blue/Customized colors
SMD2835
LED/m:240leds/m in tow rows
LED chip:Epistar/Sanan/lumileds
3ounce copper on PCB
25mm cuttable unit
This is an one color LED strip
Each 6led in a group, we can cut from the cut line with 6leds
With240pcs SMD2835 white LED per meter in tow rows
5meters/reel is standard package
10mm PCB width in standard
The PCB is made by 3 Ounce thickness copper,all soldering Pads
are big, allowing you to easily cut and reconnect
DC24V constant voltage operation
Both ends have 2pins bare wires for powering cables
3M tape attached on backside of the FPC
5 different waterproof types :IP20,IP54, IP65, IP67,IP68
Widely ue in the roof decorations, bathroom lighting,cabinet lighting etc.
Main Parameters (SMD2835 White,3/6led cuttalbe)
Item No.
S15W2835L240CV24
Voltage
24V DC
Power
Typical 19.2Watt/meter,Max 24Watt/meter
CRI
RA 80/90/95
LED Type
SMD 2835
LEDs/m
240PCS (120led *2 rows)
Cutting unit
25mm(6led)
Lumen
1350lm/m in standard, 1536lm/m in Max
Available colors
1800K/2000K/3000K/4000K/6000K/red/blue/green/yellow/ice blue
IP Rate
IP20/IP64/IP65/IP67
